| Material | stainless steel wire 301, 302, 304, 304L, 316, 316L, 321 |
| Weaving | Pre-crimping before Weaving. In two-way separated wave bending, locked bending, flat-topped curved, two-way bending, one-way separated wave bending. |
| Features | ①High tension: Much higher tension than common polyester mesh and smooth tension; ②Super precision: Uniform wire diameter and aperture with extremely low difference; ③Low elongation: Very small elongation of wire mesh at high tension; ④High flexibility: The wire mesh will not lose elasticity at extreme tension; ⑤High corrosion resistance: The excellent corrosion resistance of stainless steel wire exceeds polyester fiber; Non-electrostatic: To avoid affects of non-electrostatic for print and ensure the safety of printing;Good heat-melting resistance: Special features of stainless wire mesh. Suitable for heat-melting ink; Good solvent resistance: To avoid the affects of any solvents to wire mesh and to ensure the safety of print screen. |
Crimped wire mesh specifications:
Length and width specifications: 1mX25m 1mX30m 1.2mX25m 1.2mX30m
Size Chart:
| Wire Gauge SWG | Wire Diameter (mm) | Mesh/Inch | Aperture(mm) | Weight(kg/m²) |
| 14 | 2 | 21 | 1 | 4.2 |
| 8 | 4.05 | 18 | 1 | 15 |
| 25 | 0.5 | 20 | 0.61 | 2.6 |
| 23 | 0.61 | 18 | 0.8 | 3.4 |
| 24 | 0.55 | 16 | 0.1 | 2.5 |
| 24 | 0.55 | 14 | 0.12 | 4 |
| 22 | 0.71 | 12 | 0.14 | 2.94 |
| 19 | 1 | 2.3 | 0.18 | 1.45 |
| 6 | 4.8 | 1.2 | 2 | 20 |
| 6 | 4.8 | 1 | 2 | 20 |
| 6 | 4.8 | 0.7 | 3 | 14 |
| 14 | 2 | 5.08 | 0.3 | 12 |
| 14 | 2 | 2.1 | 1 | 2.5 |
| 14 | 2 | 3.6 | 1.5 | 1.9 |
